Marvel 18" x 20" Vertical Tilt Frame Band Saw, Series 8 Mark I

Marvel Series 8 Mark I Vertical Tilt Frame Band Saw

Serial # 822222-W
Asset # 12199

Specifications:
Capacity - Nominal    18" x 20"
Maximum Capacity    18" x 22 1/2"
Capacity at 45 Degrees    18" x 13"
Blade Dimensions    14' 6" x 1" x .035"
Table Working Surface    33" x 24 1/4"
Table Height     34 1/2"
Number of T-Slots in Table    4
Max. Vise Opening    21"
Motor    2 HP, 1800 RPM
Blade Speeds    50-450 ft/min
Height    88 1/4"
Dimensions    54 1/2" x 95"
Weight    2670 lbs.
Priced As-IS

Preliminary Specifications - Subject to Verification
